Overview
The Tata Signa 1923.K is a heavy-duty 6-wheeler tipper truck engineered to excel in many demanding applications, including mining operations, quarrying, construction projects, and material transportation. Powered by a Cummins ISBe 5.6L BS6 compliant diesel engine that produces 220 HP and 850 Nm of torque, this 18,500 kg GVW vehicle delivers an impressive balance of power and fuel efficiency with a mileage of 3.5-4.5 kmpl. The truck features Tata’s advanced G-950 6-speed manual transmission with twin cone synchro technology, along with a 3-mode fuel economy switch that allows drivers to optimize fuel consumption based on load and terrain conditions. Built on a robust ladder-type chassis frame, the Signa 1923.K comes equipped with an 11.5-tonne capacity RA 110 rear axle offering 52% improved gradeability. The vehicle offers a payload capacity of approximately 10,000 kg and is available with either a 7-scoop tipper or 10.5 m³ box body configuration. Modern comfort and safety features include a telematics-enabled anti-fuel theft system, real-time vehicle tracking, tilt and telescopic steering, air conditioning, LED taillamps, and a comprehensive instrument cluster. Tata signa 1923.k also offers cruise control, that will help drivers in long runs.With a 300-liter HDPE fuel tank for extended operational range and a generous 3-year/6 lakh km warranty on the driveline, the Tata Signa 1923.K is priced between ₹28.91 to ₹36.10 lakh (ex-showroom)
Available Body Types
Tata Signa 1923.K Variants & Price
| Variant Name | Ex-Showroom Price | Action |
|---|---|---|
|
Tata Signa 1923.K
|
₹2,891,000 |
Get On-Road Price |
Technical Specifications
| Engine Model | Cummins ISBe 5.6 BS6 |
| Displacement | 5600 cc |
| Max Power | 220 HP @ 2300 rpm |
| Max Torque | 850 Nm @ 1000-1600 rpm |
| No. of Cylinders | 6 |
| Fuel System | Common Rail Direct Injection |
| Emission Norm | BS6 |
| Mileage | 3.5-4.5 kmpl |
| Fuel Tank Capacity | 300 Litres |
| Gross Vehicle Weight (GVW) | 18500 kg |
| Payload Capacity | 10000 kg |
| Kerb Weight | 8500 kg |
| Rated Payload | 10000 kg |
| Gradeability | 30% |
| Max Speed | 80 km/h |
| Overall Length | 6134 mm |
| Overall Width | 2510 mm |
| Overall Height | 3010 mm |
| Wheelbase | 3580 mm |
| Turning Radius | 7.5 m |
| Transmission | G950 DD 6-Speed Manual |
| Clutch | 380 mm Push Type Single Plate Dry Friction |
| Axle Configuration | 4x2 |
| Front Axle | Forged I-Beam Reverse Elliot Type - Drop Beam |
| Rear Axle | Single Reduction, Extra Heavy Duty, Hypoid Gears with Differential Lock |
| Front Suspension | Leaf Springs |
| Rear Suspension | Semi-Elliptical Leaf Springs with Helper Springs |
| Front Brake | Air Brake with Dual Circuit |
| Rear Brake | Air Brake with Dual Circuit |
| Parking Brake | Spring Brake on Rear Axle |
| ABS | Standard |
| Front Tyre | 295/95 D20 |
| Rear Tyre | 295/95 D20 |
| No. of Tyres | 6 |
| Wheel Type | Steel |
| Cabin Type | Day Cab |
| Seating Capacity | 1 |
| Air Conditioning | Optional |
| Power Steering | Standard |
| Battery | 24V 240Ah |
| Alternator | 28V 100A |
Tata Signa 1923.K Pros & Cons
- Powerful Engine Performance: Cummins ISBe 5.6L BS6 engine delivers 220 HP and 850 Nm torque, providing excellent power for heavy-duty operations<br />
- Superior Gradeability: RA 110 rear axle offers 52% improvement in uphill performance, ideal for hilly terrain and loaded conditions<br />
- Fuel Efficiency Features: 3-mode fuel economy switch allows optimization based on load and terrain, helping reduce operating costs<br />
- High Payload Capacity: Can carry approximately 10,000 kg payload with 18,500 kg GVW<br />
- Advanced Safety Technology: Equipped with telematics, real-time tracking, geo-fencing, anti-fuel theft system, and panic button<br />
- Excellent Warranty Coverage: 6lakh km/6,000 hours warranty on gearbox and driveline provides long-term peace of mind<br />
- Cruise Control
- No Hill Hold Feature: Lacks hill hold assist, which can make uphill starts challenging when fully loaded<br />
- Not Available in Automatic Transmission: Only comes with manual transmission (note: one source contradicts this, but most indicate manual only)
EMI Calculator
Calculate Your Monthly EMI
Total Cost of Ownership (TCO)
Calculate 5-Year Operating Cost
Frequently Asked Questions
What is the payload capacity of Tata Signa 1923.K?
The Tata Signa 1923.K offers 10000 kg. Contact dealer for specific configuration details.
What is the mileage?
Delivers 3.5-4.5 kmpl. Actual mileage varies with load and driving conditions.
What is the GVW (Gross Vehicle Weight)?
GVW is 18500 kg.
Is financing available?
Yes, various financing options available with competitive interest rates. Contact dealer for EMI plans.
What is the warranty period?
Standard manufacturer warranty applies. Extended warranty options available.
Service network availability?
Wide service network across India with trained technicians and genuine spare parts.
Suitable for inter-state operations?
Yes, complies with all regulatory requirements for inter-state commercial operations.
What emission norm does it meet?
Meets BS6 emission standards.
